Super Mini PTZ IP Camera HD 5MP Dome Outdoor Waterproof CCTV Security PTZ Cameras 4X Optical Zoom Lens 40M IR P2P
This unit is 802.3af POE. This unit can also be used with a 12VDC2A power source as well.
Product overview:
- 5.0MP 1/2.5 AR0521 Low illumination CMOS,4X optical zoom;
- Resolution: 5MP: 2592*1944,25/30fps
- Support Onvif protocol work with Hikvision , XM
- Support lightning protection, anti surge;
- Outdoor speed dome camera protection grade:IP66;
- Support Chinese and English IE interface and have operation tips function, user interface friendly;
Feature:
- Adopt 4pcs infrared light, Effective exposure distance up to 40m
- Horizontal rotation 350 ° continuous rotation, Vertical 0 ° -90 °, support automatic flip, no monitoring blind spot.
- Pan speed max 25°/s, tilt speed max 20°/s
- Pan speed 0°/s~25°/s, tilt speed 0°/s~20°/s,
- Support 16 preset;1 patrols;1 patterns; support AB scan;
- Proportional zoom function, rotation speed can be adjusted automatically according to zoom multiples
- Support park action, presets/pattern/patrol/pan scan can invoke automatically after a defined time of inactivity
- Support Mobile Phone APP View: Hisee
- Support PoE function, Standard IEEE802.3af/at
(Power Adapter NOT INCLUDED, Sold Separately)
Specifications:
Model | HD46F-5MP |
Image sensor | HI3516D+AR0521 |
Resolution | 5MP:2592*1944, 25/30fps |
Low illumination | color:0.2Lux @ F1.2;black-white 0.01Lux @ F1.2 |
Signal / scan system | PAL/NTSC; Progressive |
Electronic shutter | Auto/manual(1/5-1/50000 ) |
Day-night mode | Auto ICR |
Optical zoom | 2.8-12mm;4X Optical Zoom |
Pan angel | 89.9°-26.2° |
IR distance | 40M |
Pan speed | Horizontal rotation 350 ° continuous rotation,0°~25°/S |
Tilt speed | 0-20°/S |
Tilt range | 0°-90° |
Proportional zoom | Support, change the speed based on the zoom |
Preset | 16 |
Patrol | 1 |
Pattern scan | 1 |
A.B scan | Support |
Park function | Support, preset, cruise, pattern scan, two-point line sweep, horizontal automatic |
Max image size | 2592*1944 |
Output bit rate | 32Kbps-16Mbps |
Video compression | H.265/H.264/MJPEG |
Network protocol | TCP/IP,HTTP,DHCP,DNS,DDNS,RTP, RTSP, PPPoE, SMTP,NTP, UPnP |
Interface protocol | Onvif, hikvision ,xm protocol |
Network interface | Built-in RJ45 network interface, support 10M/100M IP DATA |
PTZ control protocol | Pelco-d, Pelco-p |
Power consumption | DC 12V2A,10W(max) Not Included In The Packing |
Support 48V POE Function | YES |
Working tem and hum | -30℃~+60℃,≤90%RH(no frostless) |
Protection grade | TVS3000V lightning protection, surge protection and voltage |
Transient protection, weather proof (for outdoor): IP66 | |
Package Weight(kg) | 0.7 |
Size(D×H)(mm) | 110*95 |
- 1 *PTZ Dome IP Camera
- 1 * Screws Bag
- 1 *CD
- 1* User Manual
