2MP Indoor Fisheye IP Dome Camera 1.7mm Lens

2MP Indoor Fisheye IP Dome Camera 1.7mm Lens

SKU: WIP-FISHEYE-MINI
Regular price $189.00 USD
Regular price Sale price $189.00 USD
Sale Sold out
Shipping calculated at checkout.

2 Megapixel ONVIF compatible Mini Indoor IP Camera with Fisheye 1.7mm Lens NO Infrared, Ceiling Mount , 12VDC

View full details


2MP Indoor Fisheye IP Dome Camera 1.7mm Lens


* High Resolution 3.0 Megapixel 1/3'' CMOS Sensor  2MP@30fps
* 2304*1296P resolution 20fps
* Support H.265 encode, compare with H.264, transit same quality image only need half of the bandwidth; Record same quality image only need half of the storage;
* Also support H.264 encode, so it can be compatible with both H.264 and H.265 device.
* P2P Remote Viewing
* Support Motion detection, Email Alarm function
* Support iPhone, Android smartphone
* Support Multi-Language
* Metal Material Shell

Resolution: 2304 x 1296P 3.0 Mega Pixels
Sensor: FH8852+GC2053
Min illumination: 0.1Lux @(F1.2,AGC ON) ,0 Lux with IR
Frame rate: 3MP/20fps  -  2MP/30fps
Lens: 1.7mm Fisheye Lens
Onvif Port: 6688
Lens interface type: M12
Shutter: 1/25 seconds -1/100,000 seconds
Compression Format: H.265/H.264
Storage: NVR or Computer
IP address: Dynamic (Default)/Static
Smart alarm: Motion detection, Email alarm
Support protocol: ONVIIF, HTTP, TCP/IP, ICMP, RTSP, RTP, UDP, RTCP, SMTP, DHCP, DNS, PPPoE, NTP
Ethernet: 10M/100M mbps Ethernet (RJ-45)

Functions:

  • Title OSD: Supports channel name, date, and video stream information overlay;
  • Privacy Mask: 4 configurable regions
  • Image Orientation: image flip and mirror
  • Auto Exposure Control (AEC); Auto White Balance (AWB); Auto Band Filter (ABF)
  • Auto Black Level Calibration (ABLC)
  • Network protocol: TCP/IP UDP RTP RTSP RTCP HTTP DNS DDNS DHCP FTP NTP PPPOE SMTP UPNP
  • ONVIF protocols: Support 2.0 Version
  • Remote View: IE 6.0 or later, Firefox
  • Network Interface: 10/100M BASE-TX,RJ-45 connector
Video encoding:
  • Video Compression: H.264 main profile, support dual stream, AVI format; support 0.1M~6Mpbs bit rate adjustable; support 1~30fps adjust
  • Main Stream: 1920*1080P
  • Video Bitrates: 32Kbps~4Mbps,Supports CBR/VBR
General Specifications:
  • Operating Temperature: -20 °C ~ 50 °C (-4 °F ~ 122 °F)
  • Operating Humidity: 0% -85% RH
  • Power: DC12V, PoE (802.3af)
  • Power Consumption: 9W (MAX)
Package Included:
  • 1x 2.0 MP 1080P IP Camera in/outdoor HD with PoE Function
  • 1x CD Manual
Notes: This model is suitable DC12, 1.5A power adapter, but not included
